G80 Eye Bolt Features:

• The Product is forged of alloy steel ,quenched and tempered

• Product 100% magnetic particle inspected

• 100% proof test at 2.5 times the working load limit

• Sampling break test for each batch

• 20000 cycles fatigue test at 1.5 times the working load limit

• Ensure 4 times safety factor at any lifting angle

• Ring manufacturing and testing are conducted according to EN1677-1

G80 Eye Bolt Typical Applications:

• Lifting and hoisting field: It can be used in various engineering lifting machinery, such as cranes in ports, lifting equipment in mines, etc., as a lifting point to connect lifting chains or wire ropes for lifting heavy objects. It is also commonly used for the installation and disassembly of large mechanical equipment, such as lifting large machine tools in factories. By installing G80 eye bolts at the designated lifting point of the machine tool, it is convenient for the crane to lift the machine tool and move it to the designated position.

• Construction industry: At the construction site, it can be used to fix and hoist building components, such as prefabricated panels, steel structure components, etc. It can also be used in slope tunnels, shaft management and protection projects, by anchoring eye bolts in rocks or concrete, connecting protective nets or supporting structures, to play a safety protection role. In addition, when building scaffolding, it can be used as a connection point to fix the relevant parts of the scaffolding and enhance the stability of the scaffolding.

• Transportation field: In shipbuilding, it can be used to lift hull parts or fix shipboard equipment. In automobile manufacturing, it can be used to lift automobile parts such as car bodies and engines on production lines. At the same time, in highway transportation of large items, it can be used to fix the goods. The eye bolts are installed at specific positions of the transport vehicle or goods, and the ropes or chains are connected to prevent the goods from moving during transportation.
