WST060 H408 Light Type Champion Snatch Block Double Sheave with Hook Feature

• Excellent and strong material: usually made of carbon steel or alloy steel, the hook and side plate are forged alloy steel and heat-treated, with high strength and good toughness, can withstand large loads, and can adapt to a variety of complex working conditions.

• Exquisite structural design: equipped with forged swivel hook or swivel shackle, easy to connect and use. The side plate design prevents the rope from getting stuck and ensures smooth operation. By removing a bolt, the wire rope can be easily inserted into the two pulleys for easy installation and maintenance.

• Diverse sizes: There are multiple options from 4.5 inches to 18 inches, and the rated load range is from 4 tons to 15 tons, which can meet different lifting needs and adapt to a variety of operating scenarios.

• Wide range of compatible ropes: It can adapt to wire ropes of various diameters such as 10mm to 19mm, which can meet the use requirements of wire ropes of different thicknesses and has a wide range of applications.

• Flexible bearing configuration: bronze bushings or rolling bearings can be equipped. Bronze bushings have good wear resistance and self-lubrication, while rolling bearings can reduce friction and improve the rotation efficiency of the pulley. Users can choose according to their needs.

• Convenient lubrication and maintenance: The center pin is equipped with pressure lubrication accessories for easy regular lubrication, which can reduce component wear and extend service life.

• Reliable safety performance: It meets or exceeds the ASME B30.26 standard, and has strict guarantees in terms of identification, ductility, design factor, verification load and temperature. It also meets key performance requirements such as fatigue life and material traceability, and is safe and guaranteed.

WST060 H408 Light Type Champion Snatch Block Double Sheave with Hook Typical applications

• Hoisting operation: In the hoisting of various large equipment, it can be used in conjunction with a crane to accurately hoist the equipment to the designated position by changing the force direction of the wire rope. It can also assist in lifting steel beams, steel columns and other components during the installation of steel structures. It can also be used for cargo loading and unloading in ports, warehouses and other places to improve cargo loading and unloading efficiency.

• Off-road rescue: It is often used in off-road rescue scenarios for vehicles such as off-road vehicles. When a vehicle is in trouble, it can be used in conjunction with a winch to increase the pulling force by changing the direction of the winch wire rope to pull the trapped vehicle out of trouble. It can also flexibly adjust the pulling force direction according to actual conditions to adapt to different rescue environments.

• Construction: It can be installed on tower cranes, gantry cranes and other equipment for construction to assist in lifting construction materials and tools. In the construction of high-rise buildings, it can lift materials such as steel bars and formwork to the high working surface. It can also be used in some small construction projects with equipment such as winches to complete the lifting and movement of small components.

• Mining: In mines, it can be used to lift ore, equipment, etc. For example, in underground mines, the mined ore is hoisted from underground to the surface, or in open-pit mines, it assists in moving mining equipment, transporting ore, etc. It can also cooperate with the lifting equipment in the mine to install and repair large mining machinery.

• Ship operations: In the process of shipbuilding, it can be used to hoist ship parts to facilitate hull assembly. During ship navigation, it can be used to raise and lower the sails and adjust the angle of the sails to obtain better wind power. It can also assist in loading and unloading cargo when the ship is docked at the dock, or hoist maintenance tools and parts when the ship is repaired.

• Forestry felling: At the forest felling site, the felled trees can be hoisted to the designated transportation location for subsequent transportation. It can also be used to hoist logs to processing equipment in the wood processing plant, or to hoist the processed wood to the warehouse for storage.
